AZPFF-10-014/005RSG2020MB
Category: Rexroth
CODE: 0510555005
CODE: 0510555005
Availability: Currently not available
Notify me about availability
Check deliveries
Product description
The primary function of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow rate and pressure). To reduce losses (leakage and heat), Rexroth external gear pumps are designed for high efficiency. This high efficiency is achieved through backlash compensation and high-precision manufacturing technology.
Product features
- Producent: Rexroth
- Seria pompy: AZPFF
- Pump type: Double toothed
- Drive shaft: Tapered 1:5 for G flange
- Working volume: 14 + 5 cm3/obr
- Front cover: Unit bearing diameter 80 mm type 2
- Turning direction: Direction of rotation to the right
- Action: Pompa
- Max. working pressure (continuous): 280 bar
- Gross weight: 6.5 kg
- Enclosure material: Aluminium
- Max. flow PU2: 192.5 l/min
- Max. intermittent pressure of pumping unit 1: 280 bar
- Max. intermittent pressure of pumping unit 2: 280 bar
- Roller type: Conical 1:5
- Maximum RPM: 3500 rpm
- Shaft seal: NBR
- Construction variant: Design variant F (4 ... 28 cm³/rev)
- Pump design variant 2: Design variant F (4 ... 28 cm³/rev)
- Net weight: 6.5 kg
- Noise level: Standardowy poziom hałasu
- Nominal size: 14 cm³/rev
- Cable connection: Square collar
- Pump 2 cable connection: Square collar
- Product: External gear assembly
- End cover: Standard
- Seal material: NBR
- Number: Shaft Ø 18 mm
- Pump size 2: 55 cm³/rev
- Version: zabezpieczenie przed korozją,
- Libra: 6.5 kg
