Rexroth 4WE6Y6X/EG24N9K4 directional control valve (ex. 0810090107)
Category: Rexroth
CODE: R900561276
CODE: R900561276
Availability: Available (quantity: 1) , shipping within 10 dni
Check deliveries
Product description
Industrial hydraulic valve in a high performance range. Reliable switching of the oil flow direction according to hydraulic symbol
Product features
- Connection diagram: ISO 4401-03-02-0-05
- ECLASS_13_Classification: 51-44-01-02
- Electric connection description: Connector, 3-pole (2 + PE) according to EN 175301-803
- Plug: Connector, 3-pole (2 + PE)
- Gross weight: 1.455 kg
- Hydraulic fluid: HL,HLP,HLPD,HVLP,HVLPD,HFC
- Max flow rate: 70 l/min
- Net weight: 1.455 kg
- Max. working pressure: 350 bar
- Product family: WE6../E
- Seals: NBR
- Nominal size: 6
- Slider graphic symbol: Symbol Y
- Supply voltage: 24 VDC
- Connection type: Subplate mounting
- Number of connections: 4
- Valve position number: 2
- Libra: 1.46 kg






Rozdzielacze suwakowe sterowane bezpośrednio elektromagnesem
