Directional slide distributor Rexroth 5-4WE 10 J5X/EG24N9K4/V

Category: Rexroth

CODE: R901339722

CODE: R901339722

Availability: Currently not available

Notify me about availability

Price available on request +48 42 712 66 07

Ask about the product

Industrial hydraulic valve in a high performance range. Reliable switching of the oil flow direction according to hydraulic symbol

Connection diagram: ISO 4401-05-04-0-05
ECLASS_13_Classification: 51-44-01-02
Electric connection description: Connector, 3-pole (2 + PE) according to EN 175301-803
Plug: Connector, 3-pole (2 + PE)
Gross weight: 5.6 kg
Hydraulic fluid: HL,HLP,HLPD,HVLP,HVLPD,HETG,HFC,HEES,HEPG,HFDU,HFDR
Max flow rate: 125 l/min
Net weight: 5.6 kg
Max. working pressure: 350 bar
Product family: 5-.WE10../E
Seals: FKM
Nominal size: 10
Slider graphic symbol: Symbol J
Supply voltage: 24 VDC
Connection type: Subplate mounting
Number of connections: 4
Valve position number: 3
Libra: 5.6 kg
