Sauer Danfoss 111.25.013.0A gear hydraulic pump
Category: Sauer Danfoss
CODE: WH SNP3/A33LSSEB
CODE: WH SNP3/A33LSSEB
Availability: Currently not available
Notify me about availability
Check deliveries
Product description
SNP3NN/033LN07SAP1A4A3NNNN/NNNNN
111.25.013.0ASNP3NN/033LN07SAP1A4A3NNNN/NNNNN
111.25.013.0A SNP3 Group 3 Gear Pump Anti-Clockwise 33 cc/rev SAE B 13 Tooth Spline SAE B 101.6mm Pilot 2 bolt SAE split flange Single Pump Sanderson
Connections:
A3 - 25x26,19x52,37x3/8-16UNC
A4 - 31x30,18x58,72x7/16-14UNC
Product features
- Producent: Danfoss
- Comparison code: 111.25.013.0A
- Working volume: 33,1 cm3/obr
- Turning direction: Left
- Flange type: SAE-B
- Centering diameter: 101,6 mm
- Roller type: Splined - 13 teeth
- Pump type: Toothed
Dokumentacja techniczna
