Danfoss SNP2 C17L ZXBB gear hydraulic pump
Category: O.K. White
CODE: WH SNP/C17LZXBB
CODE: WH SNP/C17LZXBB
Availability: Currently not available
Notify me about availability
Check deliveries
Product description
Danfoss 111.20.326.00 gear hydraulic pump
SNP2NN-/-017-RN-01-DA-P1-B7-B5-NN-NN-/-NNN-NN
Ports:
B5 -15x35xM6
B7 - 20x40xM6
Product features
- Producent: Danfoss
- Working volume: 16,8 cm3/obr
- Turning direction: Right
- Max. working pressure (continuous): 250 bar
- Centering diameter: 36,5 mm
- Roller type: Spline DIN 5482 B17x14-L10
- Flange type: 71.5/96.2mm, 4 bolts
- Pump type: Toothed
- Comparison code: 111.20.326.00, SNP2NN/017RN01DAP1B7B5NNNN/NNNNN
