Binotto NPH-90 UNI R gear pump
Category: UNI
CODE: 10501100906
CODE: 10501100906
Availability: Currently not available
Notify me about availability
Price available on request +48 42 712 66 07
Ask about the product
Product description
Connection ports:
- IN: G 1 1/4"
- OUT1: G 1"
- OUT2: G 3/4"
Product features
- Producent: OMFB Binotto
- Seria pompy: NPH UNI
- Pump type: Toothed
- Working volume: 90,43 cm3/obr
- Turning direction: Right
- Flange type: UNI
- Centering diameter: 52 mm
- Roller type: Spline 6x21x25
- Typ portu: BSP Gwinty
- Compressing port: G 1"
- Suction port: G 1 1/4"
Dane techniczne 2005 en
