Baltrotors 3t hydraulic rotator with 140x140mm, 4x17mm flange
Product code GR30PF
Availability: Currently not available
Notify me about availability
Product features:
Top pin diameter (crane) - 25 mm
Rotator assembly - 60mm
Tool assembly - Flange 140x140 mm; 4x17 mm
Maximum static load - 30 kN
Maximum dynamic load - 15 kN
Safe working load - 3000 kg
working pressure - 250 bar
Oil flow - 20 l/min
Connection type - G 3/8" x G 3/8"
Torque - 1000 Nm
Type - GR
Libra - 20 kg
Producent - Baltrotors
Description - Baltrotors GR30PF hydraulic rotator (Modification of GR30 rotator with square 140 mm flange bottom connection)
