Product code W1B1B11010
Availability: Available
(quantity: 2)
Product features:
Description - The shaft is manufactured according to the new PN-EN-12965_2020 standard. The Waryński R Series shafts were created to better meet the needs of our customers. The revised design has increased the service life and durability of our products by over 15%. Thanks to the use of a specialized locking system, Waryński shafts guarantee quick assembly and safety, and are compliant with the new standard. The high quality of our products is guaranteed by forks made of high-carbon steel, crosspieces equipped with special, increased-strength bearings, and Waryński PTO shaft housings resistant to mechanical impact, UV exposure, and low temperatures.
Producent - WARYNSKI
Tractor mount - 1 3/8" - Z6 cal
Attachment to the machine - 1 3/8" - Z6 cal
Telescopic connector type - Rura trójkątna
Maximum length - 1580 mm
Nominal power - 12 ( 16 ) KW ( KM )
Inner tube thickness - 29 mm
Outer pipe thickness - 36 mm
Bearing diameter - 22 mm
Height of the cross - 54 mm
Collaborates with - Widłak zewnętrzny - WR227101, Krzyżak - WR219101, Widłak rury wew. - WR219107, Widłak rury zew. - WR219106, Rura wewnętrzna - WR2311890, Rura zewnętrzna - WR2321890, Obudowa - WR21911129
Torque - 210 Nm
Working angle - Max 17°
Inner pipe wall thickness - 4 mm
Outer pipe wall thickness - 3,2 mm
Clutch release torque - Brak Nm
Clutch from the Machine side - Brak
Clutch from Tractor side - Brak
