Product code W-ORBS-50-OR
Availability: Available
(quantity: 4)
Product features:
Producent - Waryński
Geometric volume - 50cc
Type - OR - System Open Center - z reakcją z kół na kierownicę
Libra - 5,7 kg
Connection threads - 1/2" BSP
Overflow valve setting - 14.0/140 Mpa/bar
Column connection - splined 16/32-12-30° (SAE), diameter ø25.4
Shock valve setting - 20.0/200 Mpa/bar
Max. supply pressure - 17.5/175 Mpa/bar
Max. return pressure - 2.5/25 Mpa/bar
Recommended oil flow - 5 l/min
Description - Hydrostatic steering valve W-ORBS-OR 50 cm3/rev with valves (Open Center System - with reaction from wheels to steering wheel) Waryński. Orbitrols of the W-ORBS (OR) series have a compact and solid construction, allowing for light and smooth operation of the steering system. The principle of operation of the OPEN CENTER REACTION system - popular, among others, in orchard tractors moving in difficult terrain. The driver / operator of the tractor, driving between heaps, feels the transfer of vibrations on his steering wheel. Thanks to this, he has time to correct the driving path, which at the same time gives the possibility of not damaging the crops. In this system, the oil circulates all the time and freely passes through the orbitrol, the return line and pours into the tank (the pump is relieved when the steering wheel is not used). All types of pressure on the wheels caused by moving in difficult and uneven terrain are transferred to the steering wheel. Hydraulic power steering guarantees high precision of equipment control while maintaining low failure rate.
